XQY6-24 Concrete Brick Block Making Machine

1. Tight-fixed in designing,stable in function,convenient in maintaining,high in automation,high output in making blocks,fewer in occupying the space and competitive in price based on quality;on this machine,automatically feeding block,feeding material and material arranging is the base for high production efficiency and stable quality.
2. Machine,electricity,hydraulic are all combined together and controlled by PLC with the optional locking password to protect the running with safety.Main control table is with computerized operation screener(Chinese menu,LCD touching screener),which can materialize the parameter setting,single collecting along with the machine and breakdown analyzing,thus the machine can keep in the best working status.By long-distance communication can materialize the long-distance monitoring,breakdown seeking and system updating.
3. Vibration system is perfect in designing and high in efficiency.Compressing and vibration are combined to guarantee the density of the products.
4. Horizontal and vertical structure is optional for customers to choose.Horizontal structure is facilitating to feed the surface material,which can produce the colorful road surface blocks;while vertical structure can save the pallets conveying time,which fast the block feeding.
5. This machine is wildly used,which can produce standard block,hollow block,road surface block and so on.

Main Machine Overall size(L×M×H mm): 6300×2000×2900

Pallet Size (L L×M×H mm):850×680

Molding Periodicity (differs from the different products):15-30 seconds

Machine Power:36KW           Machine Weight: ～6t

Molding bricks quantity:

Standard block   32pcs/per mold

Eight-hole block 15pcs/per mold

Hollow block     6pcs/per mold

The Automatic Concrete Brick Making Machine is a cutting-edge solution designed to revolutionize the production of concrete bricks. This advanced machine allows for the efficient, high-volume manufacturing of durable, high-quality concrete bricks with minimal labor input. Featuring automated controls, the machine offers precision in every cycle, ensuring uniformity in the shape, size, and texture of each brick. It’s ideal for businesses looking to scale their production while maintaining exceptional quality standards.

The automatic concrete brick making machine operates with a fully automated system that reduces human intervention, saving time and reducing the risk of errors. It uses advanced vibration and hydraulic press technology to form the bricks with optimal compaction, ensuring strong and long-lasting products. The machine can produce a variety of brick sizes and types, making it highly versatile and suitable for different construction needs. Additionally, its user-friendly interface makes operation simple, even for those without extensive technical experience.

Built with durable materials, the Automatic Concrete Brick Making Machine is designed for long-term performance and reliability. It requires minimal maintenance and offers excellent energy efficiency, making it an economical choice for large-scale brick production. With high output capabilities, this machine is perfect for construction companies, brick manufacturers, and other industries in need of a continuous supply of quality concrete bricks.
